Advertisements are inevitable for every business and among them advertisement boards in cities and road sides need lights so that they can be seen at night. Usually a great quantity of money is wasted for electricity and someone should be there to turn them on at night and off in the morning. All this efforts and money can be saved by installing M.G solar light system. These are fully automatic and fully solar dependant lights. This light system includes solar panels, battery and L.E.D lights.
The system has light sensors so that they switch on/off automatically with the availability of natural light.
TECHNICAL FATURES OF FLYLINE SOLAR ADVERTISEMENT BOARD LIGHTS
MODELS
ASSL-3
ASSL-6
ASSL-9
ASSL-12
ASSL-18
Capacity
3 WATT
6 WATT
9 WATT
12 WATT
18 WATT
Lamp / Luminary Type
LED
LED
LED
LED
LED
Operating Voltage
12 V
12 V
12 V
12 V
12 V
Power Consumption
3.3
6.4
9.9
13.2
19.8
Luminary Equal to
9 W CFL
20 W CFL
30 W CFL
40 W CFL
60 W CFL
Driver technology
Micro Controller Based C.C.C.V.
Lamp Efficiency
90%
90%
90%
90%
90%
Working Temp.
30° C to 50° C
Working Life
50,000 to 1,00,000 Working Hours
Operation
Automatic Dusk to Down
IP Rating
IP 65
Solar photovoltaic Module
10 W
20 W
50 W
70 W
100 W
Battery Voltage
12 V
12 V
12 V
12 V
12 V
Battery capacity
7 Ah
14 Ah
40 Ah
60 Ah
80 Ah
Battery Type
Sealed Lead acid
Tubular
Autonomy
1/2 Days
Battery Box
M.S. Box with Silver painted/ powder coated
Pole
M.S. pole with Silver painted and 4 meter height
Charger Technology
Micro controlled PWM Based
Warrantee
ONE YEAR
